Description
Fresh Air Inlet
Fresh Air Inlet Design, Fresh Air Can Be Introduced To Ensure Fresh Air In The Room.
Two Return Air Modes Are Selected
Two Return Air Modes Are Selected (Back Return Air And Bottom Return Air), And The Bottom Plate Is Removed To Change The Lower Return Air.
Design Of Hanger Position
There Is A Distance Between The Hanger And The Top Cover For Easy Lifting By Hand.
New Structure
Strength Analysis Through Simulation, Optimize The Structure, Improve The Strength, Not Easily Deformed During Transportation.
Electric Control Box Built-In
Built In Electronic Control Box, And The Stuffing Quantity Is Greatly Increased.
Technical specifications table
Specifications
ZRVLD-H15/NR1DQ
ZRVLD-H22/NR1DQ
ZRVLD-H28/NR1DQ
ZRVLD-H36/NR1DQ
ZRVLD-H45/NR1DQ
ZRVLD-H56/NR1DQ
ZRVLD-H71/NR1DQ
ZRVLD-H15/NR1DQ
ZRVLD-H22/NR1DQ
ZRVLD-H28/NR1DQ
ZRVLD-H36/NR1DQ
ZRVLD-H45/NR1DQ
ZRVLD-H56/NR1DQ
ZRVLD-H71/NR1DQ
Capacity
Cooling ( kW )
1.5
2.2
2.8
3.6
4.5
5.6
7.1
Heating ( kW )
1.8
2.5
3.2
4
5
6.3
8
Electric Data
Power Supply ( V~,Hz,Ph )
240,50/60,1~220
240,50/60,1~220
240,50/60,1~220
240,50/60,1~220
240,50/60,1~220
240,50/60,1~220
240,50/60,1~220
Rated Power ( W )
31
31
31
31
31
31
65
Performance
Air Flow Volume(Tu/Hi/Mid/ Low) ( m³/h )
460/400/340
460/400/340
460/400/340
605/500/430
800/680/550
900/750/600
1145/945/700
Noise Level(Hi/Mid/Low) ( dB(A) )
30/26/22
30/26/22
30/26/22
30/28/24
30/26/22
30/26/22
36/32/28
External Static Pressure(ESP) ( Pa )
(50~0)13
(50~0)13
(50~0)13
(50~0)13
(50~0)13
(50~0)13
(50~0)13
Dimensions
W Net ( mm )
550
550
550
700
900
900
1100
D Net ( mm )
450
450
450
450
450
450
450
H Net ( mm )
198
198
198
198
198
198
198
W Packing ( mm )
715
715
715
865
1065
1065
1265
D Packing ( mm )
535
535
535
535
535
535
535
H Packing ( mm )
255
255
255
255
255
255
255
Weight
Net/Gross ( kg )
11/13.5
11/13.5
11/13.5
13/16
15.5/18.5
15.5/18.5
18.5/21.5
Pipe Diameter
Liquid Side ( mm(inch) )
(1/4)6.35
(1/4)6.35
(1/4)6.35
(1/4)6.35
(1/4)6.35
(1/4)6.35
(3/8)9.52
Gas Side ( mm(inch) )
(3/8)9.52
(3/8)9.52
(3/8)9.52
(1/2)12.7
(1/2)12.7
(1/2)12.7
(5/8)15.88
Drainage ( mm(inch) )
R1in(DN25)
R1in(DN25)
R1in(DN25)
R1in(DN25)
R1in(DN25)
R1in(DN25)
R1in(DN25)
Stuffing Quantity
20/40/40H ( Unit )
306/621/720
306/621/720
306/621/720
243/504/570
198/396/440
198/396/440
171/360/400
